It's right for you if...
You want a featherweight road race bike without top-end race pricing. You're up for racing, club rides, or solo spins up winding canyons, and don't want to compromise between climbing efficiency and aerodynamics. Plus, you get the wireless performance of SRAM's Rival AXS groupset.
The tech you get
An ultra-light OCLV 500 Carbon frame with aero tubing and lightweight IsoFlow comfort tech. A 2x12 SRAM Rival AXS wireless electronic groupset for clean shifts under pressure. Plus, it's topped off with Bontrager Aeolus Elite 35 tubeless carbon wheels.
The final word
Madone SL 6 AXS Gen 8 delivers race-worthy aerodynamics and climb crushing weight. It's a bonafide superbike in a more economical package, thanks to its 500-Series OCLV Carbon layup and workhorse AXS groupset. It offers the same frame tech as its SLR sibling, like aero tube shaping and IsoFlow comfort tech, so you can stay at the front of the pack.
View more details at Trekbikes.com
Specifications
| Weight: | Medium/Large - 8.43 kg / 18.59 lbs (with TLR sealant, no tubes) |
|---|---|
| Frame: | 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle |
| Fork: | Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle |
| Shock: | N/A |
| Front Shifter: | SRAM Rival eTap AXS |
| Front Derailleur: | SRAM Rival D1 AXS, braze-on |
| Rear Shifter: | SRAM Rival eTap AXS, 12 speed |
| Rear Derailleur: | SRAM Rival AXS |
| Crankset: | SRAM Rival AXS w/ power meter, 48/35, DUB - XS, S:165mm - M: 170mm - M/L, L:172.5mm - XL:175mm: |
| Pedals: | N/A |
| Bottom Bracket: | SRAM DUB, T47 threaded, internal bearing |
| Cassette: | SRAM XG-1250, 10-36, 12 speed |
| Chain: | SRAM Rival, 12 speed |
| Front Brake: | Sram Rival Hydraulic Flat Mount |
| Front Brake Rotor: | SRAM Paceline, rounded, centerlock, 160mm |
| Rear Brake: | Sram Rival Hydraulic Flat Mount |
| Rear Brake Rotor: | SRAM Paceline, rounded, centerlock, 160mm |
| Brake Levers: | SRAM Rival eTap AXS |
| Front Hub: | 100x12 mm thru axle |
| Front Hub Skewer: | Bontrager Switch chamfered thru axle, removable lever |
| Rear Hub: | SRAM XD-R freehub, 142x12mm thru axle |
| Rear Hub Skewer: | Bontrager Switch chamfered thru axle, removable lever |
| Rims: | Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35 mm rim depth |
| Front Tire: | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700x28mm |
| Rear Tire: | Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700x28mm |
| Handlebar: | Bontrager Comp, alloy, 31.8mm, 80mm reach, 121mm drop - XS: 36cm - S, M: 38cm - M/L, L: 40cm - XL: 42cm |
| Grips/ Bar Tape: | Trek EcoTack, black |
| Stem: | Trek RCS Pro, -7 degree - XS: 80mm - S, M: 90mm - M/L, L: 100mm - XL: 110mm |
| Headset: | RCS Headset System |
| Saddle: | Bontrager Aeolus Comp, steel rails - XS, S: 155mm - M, M/L, L, XL: 145mm |
| Seatpost: | Madone aero carbon seatpost, 0mm offset - XS, S, M: Short - M/L, L, XL: Long |
| Extras: | Bontrager TLR sealant, 180 ml/6 oz and TLR Rim strip |
Specs
| Frame: | 500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chainkeeper, T47 BB, flat mount disc, UDH, 142x12mm thru axle |
| Extras: | Bontrager TLR sealant, 180 ml/6 oz and TLR Rim strip |
| Front Derailleur: | SRAM Rival D1 AXS, braze-on |
| Seatpost: | Madone aero carbon seatpost, 0mm offset - XS, S, M: Short - M/L, L, XL: Long |
| Saddle: | Bontrager Aeolus Comp, steel rails - XS, S: 155mm - M, M/L, L, XL: 145mm |
